Mineral Rotary Dryer
- Production capacity ：0.4-76 t/h
- Weight ：9-135T
⌈ Application range ⌋：It is widely used in the drying of large particles and heavy materials in chemical, mining, metallurgical and other industries, such as limestone, slag, ore, blast furnace slag, metal powder, phosphate fertilizer, ammonium sulfate, coal powder, clay and other materials.
Gomine mine dryer adopts high temperature and rapid drying technology, with high heat transfer coefficient, high heat efficiency and high drying intensity. Combined with high speed stirring and drying and airflow drying, it can fully disperse viscous materials, greatly improve the contact area between materials and thermal media, which is conducive to the drying process. Reasonable operating parameters are selected for the mine dryer. The coal consumption and electricity consumption are more than 10-15% lower than that of the general dryer, and the hourly output is more than 10-15% higher.Drying materials for further waste into treasure, we have mature technical experience, call for advice to provide you with free guidance.
Video of Mineral Rotary Dryer:
Advantage
-
High drying strength and high efficiency
-
Simple operation environmental protection and energy saving
-
Advanced structure strong drying capacitye
Technical Data
| Model（m） | Volume | Processing capacity |
Installation Obliquity |
Highest Inlet Air Temperature |
Motor power | Weight |
| （m³） | （t/h） | （%） | （℃） | （kw） | （t） | |
| Φ1.2×8.0 | 9 | 1.9-2.4 | 3~5 | 700-800 | 7.5 | 9 |
| Φ1.2×10 | 11.3 | 2.4-3.0 | 3~5 | 700-800 | 7.5 | 11 |
| Φ1.5×12 | 21.2 | 4.5-5.7 | 3~5 | 700-800 | 15 | 18.5 |
| Φ1.5×14 | 24.7 | 5.3-6.6 | 3~5 | 700-800 | 15 | 19.7 |
| Φ1.5×15 | 26.5 | 5.7-7.1 | 3~5 | 700-800 | 15 | 20.5 |
| Φ1.8×12 | 30.5 | 6.5-8.1 | 3~5 | 700-800 | 18.5 | 21.5 |
| Φ1.8×14 | 35.6 | 7.6-9.5 | 3~5 | 700-800 | 18.5 | 23 |
| Φ2.2×12 | 45.6 | 9.7-12.2 | 3~5 | 700-800 | 22 | 33.5 |
| Φ2.2×14 | 53.2 | 11.4-14.2 | 3~5 | 700-800 | 22 | 36 |
| Φ2.2×16 | 60.8 | 13.0-16.2 | 3~5 | 700-800 | 22 | 38 |
| Φ2.4×14 | 63.3 | 13.5-16.9 | 3~5 | 700-800 | 37 | 45 |
| Φ2.4×18 | 81.4 | 17.4-21.7 | 3~5 | 700-800 | 37 | 49 |
| Φ2.4×20 | 90.4 | 19.3-24.1 | 3~5 | 700-800 | 45 | 54 |
| Φ2.4×22 | 99.5 | 21.2-26.5 | 3~5 | 700-800 | 45 | 58 |
| Φ2.6×24 | 127.4 | 27.2-34.0 | 3~5 | 700-800 | 55 | 73 |
| Φ3.0×20 | 141.3 | 30.1-37.7 | 3~5 | 700-800 | 75 | 85 |
| Φ3.0×25 | 176.6 | 37.7-47.1 | 3~5 | 700-800 | 75 | 95 |
| Φ3.2×25 | 201 | 42.9-53.6 | 3~5 | 700-800 | 90 | 110 |
| Φ3.6×28 | 285 | 60.8-76.0 | 3~5 | 700-800 | 160 | 135 |
