Intermittent Ball Mill
- Rotational speed :22-36 r/min
- Production capacity :0.29-3.6 t(each)
⌈ Application range ⌋:Widely used in cement, silicate products, new building materials, refractory materials, fertilizers, black and non-ferrous metal dressing and glass ceramics and other production industries.
The Intermittent Ball Mill (batch ball mill) is a small non-continuously produced ball mill. It has the advantages of simple structure, convenient operation, less auxiliary equipment, and high-definition products can be obtained at one time. The dry grinding method can also be used for wet grinding, the special product collection hopper when dry method, and the special slurry valve when wet method. It is applied to small production lines that have special requirements for product fineness or special materials.
Video of Intermittent Ball Mill:
Advantage
-
Autonomous design strong controllability.
-
Get the finished product in one time energy efficient.
-
High quality parts with reliable performance.
Technical Data
Model |
Effective volume(m³) |
Max.material loading per batch(t) |
Rotational speed(r/min) |
Motor power(kw) |
Weight(t) |
JXQ910×1120 |
0.68 |
0.29 |
36 |
15 |
3.3 |
JXQ1200×1400 |
1.5 |
0.64 |
32 |
22 |
5.1 |
JXQ1500×1800 |
3 |
1.3 |
28 |
45 |
8.3 |
JXQ1800×2100 |
5 |
2.1 |
25 |
75 |
13.2 |
JXQ2100×2100 |
6.8 |
2.9 |
24 |
130 |
17.9 |
JXQ2200×2400 |
8.5 |
3.6 |
22 |
155 |
21.5 |
